SiSiB® FSE9200
SiSiB® FSE9200

General Purpose Fluoro Silicone Rubber

SiSiB® FSE9200 FVMP fluorosilicone rubber is a base compound to be considered for applications exposed to non-polar fluids and solvents including fuels, oils and greases.


SiSiB® FSE9200

Technical Data


Properties / Product

FSE9230

FSE9240

Method

Hardness(Shore A)

30

40

ASTM D2240

Tensile strength (MPa) Die C

8.5

10.0

ASTM D412

Elongation at break (%) Die C

350

375

ASTM D412

Tear strength Crescent Type (KN/m)

21

25

ASTM D624

Permanent Compression set (%) (22h@180°C)

15

12

ASTM D935

Volume Swell Reference

Fuel B, (70h@23°C) (%)

22

20

ASTM D471



Properties / Product

FSE9250

FSE9260

FSE9270

FSE9280

Hardness(Shore A)

50

60

70

80

Tensile strength (MPa) Die C

10.5

9.5

9.0

8.0

Elongation at break (%) Die C

350

300

200

165

Tear strength Crescent Type (KN/m)

25

22

20

18

Permanent Compression set (%) (22h@180°C)

13

14

15

16

Volume Swell Reference

Fuel B, (70h@23°C) (%)

19

18

18

18




Curing agent: 0.55% 2,5-dimethyl-2,5-di(tert-butylperoxy)hexane (DHBP).

Curing conditions: 15min/171˚C, post-curing: 4h/200˚C in hot air


Application


  • SiSiB® FSE9200 with fluorosilicone temperature range, is used for general purpose molded, extruded, and calendered parts, like O-rings, gaskets, fuel-line quick-connect seals, oil seals, sealing strips, diaphragms, membranes, valves, hydraulic and electrical clamp blocks


Packing and Storage



  • In the unopened original container it has a shelf life of one year in a dry and cool place.
