SINOSIL-9120
SINOSIL-9120

SINOSIL™-9120 is a two-component, platinum-catalyzed, thermally conductive silicone rubber designed for electronic potting and encapsulation. It cures at room or elevated temperatures to form a soft, elastic, and electrically insulating elastomer. With excellent flowability and low hardness, it is ideal for protecting delicate components while ensuring effective heat dissipation.

SINOSIL-9120

Benefits


  • Excellent thermal conductivity (up to 2.0 W/m·K)


  • Very good flowability


  • Low hardness and elastic cured surface


  • High electrical insulation performance


  • Orange color for visual contrast


  • RoHS-compliant and halogen-free formulation


Physical Properties


Color and Appearance

White/Orange liquid

Mixing Ratio (A/B)

1:1

Pot life (25°C, min)

60

Curing time (80°C, min)

30

Curing time (hrs)

24

Viscosity (A/B, mPa·s)

6,000/5,800



Properties Cured


Appearance

Orange

Hardness (Shore A)

55

Dielectric Constant

10.0

Dielectric Strength

10-12 kV/mm

Volume Resistivity

1×10¹⁵ Ω·cm

Thermal Conductivity

1.9-2.0 W/m·K

These values are typical and are not intended for use as specifications.

Application


  • Potting and encapsulation of sensitive electronic components


  • Thermal interface for modules in power supply, automotive, and LED


  • Consumer electronics and sensor protection


  • Areas requiring soft, stress-relieving but heat-dissipating materials

Packing and Storage


SINOSIL™ 9120 is supplied in 1kg kits, 20kg pails, or 200kg drums.


In the unopened original container, it has a shelf life of one year in a dry and cool place.

Documents

DownloadSINOSIL-9120 Safety Data Sheet
