SINOSIL™ 9528 Conformal Coating is a single-component silicone coating for PCB and electronic protection. It offers exceptional resistance to moisture, corrosion, dust, shock, and extreme temperatures, ensuring reliable performance in harsh environments while extending circuit board service life.
Product | HR0930 | HR0940 | HR0950 |
Appearance | Translucent | Translucent | Translucent |
Hardness (Shore A) | 30+/-2 | 40+/-2 | 50+/-2 |
Tensile Strength (MPa) | Min.4.5 | Min.6.5 | Min.7.0 |
Elongation (%) | Min. 500 | Min. 420 | Min. 320 |
Tensile Set (%) | Max. 8.0 | Max. 8.0 | Max. 8.0 |
Curing Agent | C-15 | C-15 | C-15 |
Curing Agent Content | 1.4% | 1.4% | 1.4% |
Curing Condition | 170°C x 5min | 170°C x 5min | 170°C x 5min |
Product | HR0960 | HR0970 | HR0980 |
Appearance | Translucent | Translucent | Translucent |
Hardness (Shore A) | 60+/-2 | 70+/-2 | 80+/-2 |
Tensile Strength (MPa) | Min.7.0 | Min.7.0 | Min.6.0 |
Elongation (%) | Min. 250 | Min. 200 | Min. 120 |
Tensile Set (%) | Max. 8.0 | Max. 6.0 | Max. 6.0 |
Curing Agent | C-15 | C-15 | C-15 |
Curing Agent Content | 1.4% | 1.4% | 1.4% |
Curing Condition | 170°C x 5min | 170°C x 5min | 170°C x 5min |
Keypads
Seals and gaskets
Industrial miscellaneous molded parts
SiSiB® HR09xx is supplied in 20Kg box, with plastic bag inside.
This document does not contain the product safety information required for safe use. Before handling, please refer to the product and safety data sheets, as well as container labels, for information on safe usage, physical hazards, and health risks. Safety Data Sheet is available on the website, from the distributor, or by contacting SiSiB customer service.
